Hot and cold water cad symbols software#
Unlike in other BIM software, Fine SANI's modern BIM technology does not come at the expense of speed, it is just the opposite : you just need to draw a few single lines and the software will do the rest.Įxtensive Libraries of Elements and Fittingsįine SANI includes extensive libraries of hydraulic receptors and fittings for the bathroom, kitchen and all the different scenario you can imagine for the water supply and sewage of your building. You may for example open a project created with IDEA Architecture. You have all the required tools to create or modify the BIM model without using any other external software.Īlternatively you can also open a project created with any other 4M BIM Software and will not have to draw the building. A simple double-click on any object will display its properties for modification. You can define walls, openings, slabs, stairs and more with just a few clicks and Fine SANI will build the 3D for you. If you feel like drawing the building in 3D you simply need to focus on floor plans using the intelligent and parametric objects of the AutoBLD menu. Calculation and design are independent modules : if you have a simple project you may like to use only the calculation module to enter just the data in a table and proceed to the calculations.
You can also use our CAD features to quickly draw some walls.ĭrawing the building in 3D with BIM objects is not required to proceed to the piping calculations but you can also do it in a few clicks. Fine SANI combines a state-of-the-art BIM technology and an AutoCAD-like look and feel to help you to draw your project and networks faster and easier.ĭraw in 2D and get all the 3D Automaticallyįine SANI includes all the tools you need to draw the building in 2D or 3D but if you don't need it you can simply insert a 2D DWG drawing of the floor plan to use it as a background and focus on the plumbing installation. In Fine SANI you can create your BIM project in 2D or 3D using very simple 2D commands very familiar to any CAD user like polylines, trim, extend, entity snaps, copy. The Easiest Switch for CAD Users to BIM and Plumbing Software
